Basic Process for Calculating Piping Labor and Materials

Posted by joseph damelio on Mon, Sep 30, 2019

Calculating installation labor and material pricing for piping, fittings, valves and specialties is a function of several system type characteristics. As an example there are categories of material types; Black iron, copper, stainless steel, cast iron, plastic polybutylene, high density, polybutylene, brass. There are many other material types used but the most common plumbing material types are PVC, CPVC and PEX. Items are broken down based on either pipe or fitting type. Sizes ranges are most commonly from 1/2" to 3" diameter. Connection types are threaded, welded, flanged etc. Hanger types are band, ring, clevis, etc. The estimate should be broken down in labor and pricing tables, and on extension sheets based on material type, item type, sizes, connection type and hanger type. Hangers usually are not considered a fundamental category but should be listed separately. The takeoff may be broken down in categories so that correction multipliers may be applied based on project conditions. Project conditions may be applied based on standard floor plans, tight space, congested areas, elevated piping runs, equipment rooms, etc. with a breakdown based on different material types and system types; hot water heating, black steel, schedule 40 etc. and refrigeration system. Equipment hook ups should be taken off separately and equipment duplications may be treated as an assembly and multiplied by the number of equipment hook ups. Estimate the hookups separately. Typically non-productive labor is not included with labor however, material handling should be included when calculating total labor. Job condition multipliers may be applied and calculated separately to account for installation variations.

The piping takeoff is listed separately and is based on per foot increments. It is taken off per system, per material type, connection type and diameter. Connection materials as solder, welded connection, flange, couplings etc. should be counted and priced separately. Hanger sets are based on per footage calculation and spacing between hanger sets and counted and priced separately. Fitting takeoff is based on a per-piece basis and are listed separately from pipe on takeoff sheets. Fittings are taken off per system, per material, per connection and diameter. Fitting connection materials need to be priced and labored separately. After all items have been calculated total fitting quantities and piping extensions should be transferred to a standard fitting quantities and piping recap sheet for the totals per type of material and connection type. The totals of each category should then be transferred from the piping recap to the estimate summary. More detail for the takeoff process is included in the Wendes Mechanical Estimating Manual along with basic estimating forms, available at no charge.
